2WD Hydrostatic Steering
Side Mounted Cylinder
Kit Includes:
End 1: Inner Side Thread Diameter: 7/8inch x 18tpi
End 1: Taper end hand: RH
End 1: Outer Side Thread Diameter: M16x 1.5mm
End 1: Straight end hand: RH
End 1: Type: Straight- Female Thread
End 1: Overall Rod Length: 73mm
End 1: Taper Length: 21.6mm
End 1: Thread Length: 15mm
End 1: Taper Diameter: 20.3- 18.5mm
End 2: Inner Side Thread Diameter: 3/4inch x 20tpi
End 2: Taper end hand: RH
End 2: Outer Side Thread Diameter: M16x 1.5mm
End 2: Straight end hand: RH
End 2: Type: Straight- Male Thread
End 2: Overall Rod Length: 65mm
End 2: Taper Length: 16.5mm
End 2: Thread Length: 23mm
End 2: Taper Diameter: 20.4- 18.5mm
See images for detailed dimensions
